3 In 1 Automatic Filling Machine With Hanging Bottle Conveyor Method

Automatic Filling Machine Summarize:

Automatic Filling Machine is our new product best on Italian filling technique and our many years of production experience. Three functions washing, filling, capping are composed one body, reasonable design, beautiful outsider status, easy for operation and maintenance, full automatic. It is used for filling juice, tea and milk drinking.

Technical characteristics:

(1)This equipment adopts hanging bottle conveyor method, it is reliable. It does just need to change a small number of spare parts for changing different bottles.

(2)The filling part adopts Italian technique and low gravity type vacuum filling principle. Second open valve technique is adopted to ensure full filling process level.

(3)Spring type bottle clip, empty bottle automatic over 180 degrees by rail, to washing the bottle inside.

(4)Capping parts adopt Italy advanced technology, magnetic torque capping head. And the height of the cap part can be adjustable, it can be suitable for capping different height of the bottles.

Main configurations:

1. Main motor: made in China
2. Reduction gears: made in China
3. Touch screen: Siemens(Germany)
4. PLC: Mitsubishi(Japan)
5. Frequency converter: Mitsubishi(Japan)
6. Proximity switch, photo switch: AUTONICS(Korea)
7. Contactor, breaker: Siemens(Germany)
8. Cylinder, magnetic valve: AirTAc
9. Liquid level sensor: China
10. Main shaft bearing: made in China
11. Seal ring: Sealtech(USA)
12. Capping bearing: SKF (Sweden)
13. All the valves, tank and pipe that contact with beverage adopts SS316

Technical specs:

1. Capacity: 15000bph at 500ml PET bottle
2. Washing heads: 40pcs
3. Filling heads: 40pcs
4. Capping heads: 10pcs
5. Filling temperature: normal
6. Filling method: Gravity type
7. Compressed air: 0.5～0.6Mpa

Power of the equipment:

1. Main motor: 7.5KW
2. Cap unscramble: 0.37KW
3. Washing pump: 0.55KW
4. Water consumption: 1.5T/h (excluding product water)
5. Dimensions: 4200×2850×2400mm
6. Weight: about 6500Kg

Spare part list
